Electric Utility Vehicle
Hauler Compact HC20
Electric utility transport for grounds, maintenance and site logistics. Choose the body and seating that fit the job.
- Seats
- 2
- Range
- 90 km 56 mi
- Top speed
- ≤ 25 km/h ≤ 16 mph · adjustable
- Motor
- 5 kW 48 V AC
- Seats
- 2
- Range
- 90 km 56 mi
- Top speed
- ≤ 25 km/h ≤ 16 mph · adjustable
- Motor
- 5 kW 48 V AC
Choose your configuration
Ask for a loading plan, production timing and service parts in the written quote.
Built around the working day.
Hauler Compact HC20 at a glance
The Hauler Compact HC20 is a 2 seat electric utility vehicle from the Hauler Compact range for grounds care, maintenance and site logistics.
Its published 2025 sheet lists a 90 km (56 mile) base range, a top speed of up to 25 km/h (16 mph), a 48 V system with a 5 kW motor and an 8-hour charge time. Power comes from deep-cycle, maintenance-free lead-acid batteries.
A two-seat utility vehicle on the golf-cart chassis. Narrow enough for paths a Hauler cannot take, with a cargo bed or a drop-side box.
Dealers and fleet buyers order it wholesale by container, with configuration, colour and branding confirmed in the written quotation.
- Overall3640 x 1215 x 1900 mm143.3 x 47.8 x 74.8 in
- Overall3640 x 1215 x 1900 mm143.3 x 47.8 x 74.8 in
- SeriesHauler CompactUtility & Cargo
- Seating2configurable
2025 model year
Full specification
Reproduced in full from the manufacturer's configuration sheet, revision 20250901. Imperial values are converted, not separately measured. First-party specification; not independent validation.
Flat deck · 2 seats
| Overall L x W x H | 3640 x 1215 x 1900 mm143.3 x 47.8 x 74.8 in |
|---|---|
| Wheelbase | 2430 mm95.7 in |
| Seating capacity | 2 |
| Kerb weight | ≤ 850 kg (with batteries)≤ 1874 lb (with batteries) |
| Gross vehicle weight | 1350 kg2976 lb |
| Track, front / rear | 920 / 1010 mm36.2 / 39.8 in |
| Ground clearance | 110 mm4.3 in |
| Turning radius, outer | ≤ 5 m≤ 16.4 ft |
| Cargo deck | 1600 x 1100 x 295 mm (aluminium)63 x 43.3 x 11.6 in (aluminium) |
| Range | 90 km56 mi |
| Top speed | ≤ 25 km/h, adjustable≤ 16 mph, adjustable |
| Max gradient, laden | ≤ 15% |
| System voltage | 48 V |
| Motor | 48 V 5 kW three-phase AC induction motor, copper-wound, high torque and low noise |
| Controller | 48 V 350 A three-phase AC controller with stepless CMOS drive, regenerative electronic braking, anti-rollback, automatic downhill speed limiting and programmable mapping |
| Battery | Eight 6 V 170 Ah deep-cycle maintenance-free lead-acid batteries |
| Charger | On-board intelligent high-frequency charger, 220 V AC input, 48 V DC / 25 A output |
| Charge time | 8 hours |
| Chassis | High-strength steel ladder-frame chassis, electrophoretic primer plus powder coat |
| Front axle and suspension | Double-wishbone independent front suspension, coil springs with hydraulic dampers |
| Rear axle and suspension | Trailing-arm rear suspension with the motor coupled directly to a solid rear axle |
| Brakes | Dual-circuit hydraulic four-wheel disc brakes with electronic park brake |
| Steering | Dual-pinion rack-and-pinion steering |
| Tyres and wheels | 205/50-10 highway tyres, 6-ply rated, P820 tread on steel rims |
| Body | High-strength composite body with an injection-moulded PP front cowl for impact resistance |
| Canopy | High-strength injection-moulded ABS, black |
| Glazing | Fold-down acrylic windscreen, DOT marked |
| Floor | Diamond-pattern rubber floor |
| Seating | High-density foam cushions in PVC leatherette |
| Steering wheel | Injection-moulded steering wheel with scorecard holder (R40) |
| Dash and instrumentation | Injection-moulded dash with key switch, forward/reverse selector, hazard and lighting switches, and a round TFT display showing voltage, state of charge, speed and odometer |
| Lighting and signalling | Combination headlamps with high/low beam, DRL and flash-to-pass, indicators, combination tail lamps, horn and reversing buzzer |
| Front bumper |
|
| Additional standard equipment |
|
Drop-side box · 2 seats
| Overall L x W x H | 3640 x 1215 x 1900 mm143.3 x 47.8 x 74.8 in |
|---|---|
| Wheelbase | 2430 mm95.7 in |
| Seating capacity | 2 |
| Kerb weight | ≤ 950 kg (with batteries)≤ 2094 lb (with batteries) |
| Gross vehicle weight | 1450 kg3197 lb |
| Track, front / rear | 920 / 1010 mm36.2 / 39.8 in |
| Ground clearance | 110 mm4.3 in |
| Turning radius, outer | ≤ 5 m≤ 16.4 ft |
| Cargo box, internal | 1600 x 1100 x 1050 mm (composite box, twin rear doors and a left side door)63 x 43.3 x 41.3 in (composite box, twin rear doors and a left side door) |
| Range | 90 km56 mi |
| Top speed | ≤ 25 km/h, adjustable≤ 16 mph, adjustable |
| Max gradient, laden | ≤ 15% |
| System voltage | 48 V |
| Motor | 48 V 5 kW three-phase AC induction motor, copper-wound, high torque and low noise |
| Controller | 48 V 350 A three-phase AC controller with stepless CMOS drive, regenerative electronic braking, anti-rollback, automatic downhill speed limiting and programmable mapping |
| Battery | Eight 6 V 170 Ah deep-cycle maintenance-free lead-acid batteries |
| Charger | On-board intelligent high-frequency charger, 220 V AC input, 48 V DC / 25 A output |
| Charge time | 8 hours |
| Chassis | High-strength steel ladder-frame chassis, electrophoretic primer plus powder coat |
| Front axle and suspension | Double-wishbone independent front suspension, coil springs with hydraulic dampers |
| Rear axle and suspension | Trailing-arm rear suspension with the motor coupled directly to a solid rear axle |
| Brakes | Dual-circuit hydraulic four-wheel disc brakes with electronic park brake |
| Steering | Dual-pinion rack-and-pinion steering |
| Tyres and wheels | 205/50-10 highway tyres, 6-ply rated, P820 tread on steel rims |
| Body | High-strength composite body with an injection-moulded PP front cowl for impact resistance |
| Canopy | High-strength injection-moulded ABS, black |
| Glazing | Fold-down acrylic windscreen, DOT marked |
| Floor | Diamond-pattern rubber floor |
| Seating | High-density foam cushions in PVC leatherette |
| Steering wheel | Injection-moulded steering wheel with scorecard holder (R40) |
| Dash and instrumentation | Injection-moulded dash with key switch, forward/reverse selector, hazard and lighting switches, and a round TFT display showing voltage, state of charge, speed and odometer |
| Lighting and signalling | Combination headlamps with high/low beam, DRL and flash-to-pass, indicators, combination tail lamps, horn and reversing buzzer |
| Front bumper |
|
| Additional standard equipment |
|

Plan beyond delivery
A vehicle is part of a bigger plan.
Start with the configuration. Then plan the order, the charging setup and the service parts that keep your fleet supported.
- 01
Define your specification
Confirm seating, body options and requirements for your market.
- 02
Plan the order
Share your quantity and destination for loading and pricing.
- 03
Match the parts
Build a service package around your model and revision.
Questions about the Hauler Compact HC20
How many seats does the model Hauler Compact HC20 have?
The Hauler Compact HC20 seats 2.
How fast does the model Hauler Compact HC20 go?
Up to 25 km/h (16 mph) on the published sheet, and the top speed can be limited in the controller for your site.
What is the range of the model Hauler Compact HC20?
The published base range is 90 km (56 miles) per charge, with an 8-hour charge time. Real range depends on load, gradients and driving style.
How much does the model Hauler Compact HC20 cost?
The Hauler Compact HC20 is sold wholesale by quotation. The price depends on the configuration, battery, options, quantity and destination; send your order details for a written quote.
